OLTC POLEMOUNT


| FREQUENCY | 50/60Hz |
| HV | Up to 24,940GrdY/14,400V |
| LV | 600V and Below |
| IMPEDANCE | 1.0 ~ 5.75% |
| MAX. BIL | 125kV BIL |
| Core Type | SiFe/Amorphous |
| Core Design | Core/Shell Form |
| Standards | IEEE/IEC/NEMA |
| Insulation Oil | Mineral |
| Tank Type | Mild Steel/Stainless Steel |
| Tapping Steps | 5-Step |
| Rated Current(A) | 8A |
| Basic Components | HV/LV Bushings Pressure Relief Device Lifting Devices Ground Connectors Support Lugs OLTC |
| Optional | Wildlife Guard Surge Arrester LV Circuit Breaker MagNex Interrupter |
